Product Introduction:
The sintered felt filter element is mainly made of sintered felt filter element and stainless steel woven mesh processed by bending wave technology. The sintered felt filter element can be made into a multi-layer structure with pore size ranging from coarse to fine, and has the characteristics of high porosity and high pollutant absorption capacity; Stainless steel woven mesh is made of stainless steel wires of different diameters, and the filter element made of it has the characteristics of good strength, not easy to fall off, easy to clean, high temperature resistance, and economical use.

Product Features:
1. Good strength: Due to the support of the fourth and fifth layers, it has extremely high mechanical strength and compressive strength.
2. Easy to clean: Due to the use of surface filter materials, it has the characteristic of being used for cleaning and is particularly suitable for backwashing.
3. Easy to process: Suitable for cutting, bending, stamping, stretching, welding and other processing techniques.
4. High temperature resistance: can withstand high temperatures up to 480 ° C.
5. Corrosion resistance: Due to the use of SUS316L and 304 materials, it has strong corrosion resistance.
5. Filtering accuracy: The filtering accuracy range is 1u-100u, all of which have reliable filtering performance.
7. Stability: Due to the protection of the upper and lower layers of wire mesh and the diffusion solidification sintering process, the filter screen is not easily deformed.

Scope of application:
1. Petrochemical industry: heavy coking gas oil filtration, hydrocracking circulating oil filtration;
2. Powder homogenization of fly ash filtration and coal gasification conveying units in the coal chemical industry;
3. Purification and filtration of raw materials in the pharmaceutical and chemical industry, decarbonization and decolorization filtration of pharmaceutical intermediates, and precision filtration
4. Filtration and separation of precious metal catalysts in the fine chemical industry, as well as purification and filtration of catalytic gases
5. Clarify and filter milk, beverages, beer, mineral water, vegetable oil, etc. in the food industry;
5. Steam, compressed air, and catalyst filtration in gas purification
7. Gas welding technology (flame flashback prevention valve) and explosion-proof in the mechanical industry;
8. Probe protection in CEMS smoke detection and analysis instruments.

connection method:
Standard interfaces (such as 222, 220, 226) include quick interface connections, threaded connections, flange connections, pull rod connections, and special customized interfaces.
